Type 1055
A unique floor fixing solution for securing solid steel plate flooring, in retrofit applications, to open-mesh or open-grid flooring.
Overview
The Type 1055 floor fixing provides a unique retrofit solution enabling solid steel plate flooring to be installed over the top of existing open-mesh or open-grid flooring. Installation is carried out quickly and safely from above eliminating the need for costly scaffolding or elevated floors. As only simple hand tools are used to install the fixings, welding and hot works permits are not required. The cast stainless steel fixing and unique design provides outstanding clamping force and a secure connection.
Features & Benefits
- Fast installation from above, no need for expensive scaffolding.
- Stainless steel for high corrosion resistance.
- Superior clamping force from high quality castings.
- Safely retrofit without welding, no need for hot work permits.
- Designed for pedestrian walkways only.
Approvals
Click on an approval logo to download the certificate or report.
Properties
- Manufactured from stainless steel grade 316.
- Reaction to fire: A1 (Steel)
Durability and corrosion protection:
| Corrosivity Class | Stainless Steel |
| C1 | More than 50 years |
| C2 | More than 50 years |
| C3 | More than 50 years |
For C4 and C5 corrosion categories contact us.
Technical Specification
| Setscrew | ||||||||
|---|---|---|---|---|---|---|---|---|
| Product Code | Bolt A4-70 | Floorplate Thickness | Clamping Range | Grating Bar Width | Hole Ø | Countersunk Ø | Tightening Torque | Hexagon Key |
| Z | t | C | W | d | D | |||
| mm | mm | mm | mm | mm | Nm | mm | ||
| FG1055 | M8 | min. 6 | 35 - 56 | 3 - 8 | 40 | 50 | 11 | 5 |
Safe Working Loads (FG1055): Tensile = 1kN/bolt (4:1 FoS) Slip = 0.15kN/4 bolts (4:1 FoS)
For Characteristic Resistances when designing a connection to Eurocode 3, please refer to DoC No.115
For Characteristic Resistances when designing a connection to Eurocode 3, please refer to DoP No.015
