Application: GC01-AB

Product Type: A & B

Product Material: Malleable Iron (Zinc Plated or Hot Dip Galvanised)

Beam to beam crossing at 90°

Supporting Section: Beam
Supported Section: Beam
Connection Components: Location plate, 8 clamps and 4 bolts, nuts & washers



Safe Working Loads

Clamp Size Tension Capacity Slip Capacity
M12 23.2 kN 1.8 kN
M16 34 kN 3.4 kN
M20 58.8 kN 6 kN
M24 78.8 kN 9 kN

Send a design request to our technical support team

  • Product Category: Girder Clamps
  • Connection Type: Beam-to-Beam Crossing at 90°
  • Clamp Type: Type A & B

If you have any files that complement your technical request please attach them.

Faster to Install

No drilling or welding!

Independently Approved

Reasons to choose Lindapter

  • Save time and money

    Save time and money

    Clamping two steel sections together avoids time-consuming welding or conventional drilling and bolting.

  • Safer connections

    Safer connections

    On-site drilling and welding is avoided, removing the need for hot work permits and encouraging safer site conditions.

  • High strength

    High strength

    Lindapter clamps are manufactured from high strength materials to resist high load requirements and harsh environments.

  • Industry leading approvals

    Industry leading approvals

    Lindapter has earned a reputation synonymous with safety and reliability, gaining multiple independent approvals.

  • Adjustable

    Adjustable

    Quickly align steel sections by sliding the section into the correct position before tightening the Girder Clamp to complete the installation.

  • Free connection design

    Free connection design

    Lindapter’s experienced Engineers can design a bespoke connection based on your specific requirements free of charge.
